Carpenter's Wheel

A two car garage with a workshop corner and covered porches front and back.

Heated sq ft1,840
Beds3
Baths2.5
Stories1
Garage bays2
Width40 ft
Depth67 ft
Clear span40 ft

Buy the set

$1,695

Drafted to order. Your full construction set is finalized after purchase and emailed to you, typically within 10 business days.

Package and license

Drawn and sent in 3 business days

Add ons

When you get it

Drafted to order. Your full construction set is finalized after purchase and emailed to you, typically within 10 business days.

Total$1,695

Free preview

Every plan in this catalog previews free, watermarked floor plan, single elevation, and the basic spec page, sent to your email. Look at the sheets before you spend a dollar.

You are purchasing design documents. This is not a construction bid, a cost guarantee, or an agreement to build.

Not sure yet?

See all four elevations, the full layout, and the complete spec sheet. Free, in about a minute.

Preview is not dimensioned and is not buildable.

Build difficulty

Moderate

Moderate. Single ridge and a simple roofline, but the 40 foot span still calls for engineered trusses and a lift to set them.

An owner builder can run this job with a framing crew hired for the shell and the truss set.

About this plan

Carpenter's Wheel gives you a real workshop without giving up the house. The attached garage holds two cars and has a 12 by 9 workshop with a sink along the back wall, plus the mechanical room. From the garage you come in through a mudroom with a powder room and laundry right there, so mess never reaches the living room. Double doors on the covered front porch open into a 17 by 17 living room next to the dining room and a kitchen with an island that seats three and a 6 by 7 walk in pantry. A door off the kitchen leads to a covered porch that runs the full back of the house. The primary suite has a walk in closet and a bath with a shower and a double vanity, and Bedrooms 2 and 3 share a hall bath with its own double vanity. Outside it is lap siding under one long metal roof with cedar porch posts. Good to know: there is no foyer and the bedrooms are not split.

The structure is post frame, so the load path is simple and the interior walls are mostly partitions. That matters when you want to move a wall later, and it matters when a framing crew prices the shell. 3 bedrooms and 2.5 baths sit on one level, with 2 garage bays.

What you buy here is the document set. It is not a home, not a bid, and not a price to build. Your cost depends on your county, your site, your finishes, and who swings the hammer.

Features

Bedroom layout

  • Master on Main

Kitchen

  • Kitchen Island
  • Walk In Pantry
  • Open Floor Plan

Extra rooms

  • Mud Room

Outdoor living

  • Front Porch
  • Rear Porch

Utility

  • Laundry on Main

Accessibility

  • Single Level Living

DIY friendly

  • Simple Roofline
  • Single Ridge

Work and storage

  • Workshop

Full specifications

Plan number
NB-T2-4060-SPL-06
Style
Ranch
Heated square feet
1,840
Porch square feet
876
Total under roof
3,536
Bedrooms
3
Bathrooms
2
Half baths
1
Stories
1
Loft
No
Building width
40 ft
Building depth
67 ft
Clear span
40 ft
Wall height
9 ft
Ridge height
16 ft
Roof pitch
4:12
Framing
Post Frame
Garage bays
2
Available foundations
Monolithic Slab, Frost Protected Shallow, Crawlspace, Pier And Beam, Basement, Walkout Basement
License
Single Build License (SB-1)

What is in the set

Included

  • Foundation plan
  • Dimensioned floor plans
  • All exterior elevations
  • Building sections
  • Roof plan
  • Electrical layout
  • Typical wall sections
  • Door and window schedule

Not included

  • Engineer or architect stamp
  • Site or plot plan
  • Mechanical and plumbing design
  • Truss engineering
  • Energy calculations
  • Structural calculations for your specific wind, seismic, or snow load
Why your county may require more, and how to get it

Cost to build

National reported range, not a quote

$155 – $285 per heated square foot

$285,200 – $524,400

Band set Jun 1, 2026

This is a national range based on reported completed projects, not a quote. Your actual cost depends on your county, your site, your finishes, and who swings the hammer.

Modify this plan

Most buyers change something. Move a wall, stretch the shop, flip the entry, swap the framing. Send us what you want and we come back with a written scope and a dated range before any drawing starts.

Changes to this plan are priced by tier and drawn by American Barndos. If what you want is closer to a custom design — a different footprint, a different span, something drawn around your site — the request goes to National Barndos, and starts with a one-hour design consultation, $497. The same form covers both; pick the scope that fits.
